V-MEKO 250/300/400/400-MDR 250/300/400/400-MDROil-free compressed air – service-proven in continuous dutyMobile, powerful diaphragm compressors for the skilled trades and industryfrom ABN ABN diaphragm compressors are a genuine alternative to the piston compressor. The compactness and low weight of ABN V-MEKOs enable them to make the most of their special strengths in mobile service directly at the point of need. And thanks to ABN΄s optimized diaphragm technology there are only a few moving parts. This means very little wear and a minimum of maintenance. ABN V-MEKOs are reliable and long-lasting. A working life of 20 years is no rarity and we still keep stocks of spare parts even for these models. With pressures up to 6 bar and suction rates up to 360 l/min, these ABN compressors are predestined for use on building sites, interior finishing, redevelopment and renovation projects, and with and in plastering machines. Because of the diaphragm concept, V-MEKOs generally have no need of a buffer tank. For special applications or when higher compressed air capacities are required, we can also deliver the V-MEKO with an automatic switch-off device or in the form of a mobile and stationary compressed air center with a parallel arrangement of up to four V-MEKOs. Many benefits one machine: -
Oil-free, hence no oil changes, no disposal of used oil, no oil maintenance and no filtration expenses -
Clean, oil-free compressed air ideal for all lacquering, spraying, coating and plastering jobs -
Powerful,with an operating pressure of up to 6 bar and a suction rate of up to 360 l/min -
Compact and mobile, ideal for use on building sites and interior finishing, redevelopment and renovation projects -
Suitable for continuous duty 100% OLF* and service-proven in non-stop operation -
Rugged, reliable and operationally safe -
Long-lasting and largely maintenance-free -
EC-prototype-tested by TάV Sόddeutschland |
 | Mobile
compressor center
with 2 V-MEKO 400s
on a 90 l tank | Other
configurations
are available
to order | Model
V-MEKO400/40
W as a mobile
compressor center | Effective delivery volumes V-Meko & R-Meko
| Technical data | Max. pressure | Suction rate | AC | 3-phase AC | Motor rating | Weight | | V-MEKO 250/W | 6 bar | 250 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 250/D | 6 bar | 250 l/Min. | | X | 1,1 kW | 24 kg | | V-MEKO 250/40W | 6 bar | 250 l/Min. | X | | 1,1 kW | - | | V-MEKO 250/40D | 6 bar | 250 l/Min. | | X | 1,1 kW | - | | V-MEKO 300/W | 6 bar | 300 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 300/D | 6 bar | 300 l/Min. | | X | 1,1 kW | 24 kg | | V-MEKO 300/40W | 6 bar | 300 l/Min. | X | | 1,1 kW | - | | V-MEKO 300/40D | 6 bar | 300 l/Min. | | X | 1,1 kW | - | | V-MEKO 300/40W-VK | 6 bar | 300 l/Min. | X | | 1,1 kW | - | | V-MEKO 400/W | 6 bar | 360 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/D | 6 bar | 360 l/Min. | | X | 1,1 kW | 24 kg | | V-MEKO 400/40W | 6 bar | 360 l/Min. | X | | 1,1 kW | - | | V-MEKO 400/40D | 6 bar | 360 l/Min. | | X | 1,1 kW | - | | V-MEKO 400/90D | 6 bar | 360 l/Min. | | X | 1,1 kW | - | | V-MEKO 800/90W-Standard | 6 bar | 2 x 360 l/Min. | X | | 2 x 1,1 kW | - | | V-MEKO 800/90W | 6 bar | 2 x 360 l/Min. | X | | 2 x 1,1 kW | - | | V-MEKO 800/90D-Standard | 6 bar | 2 x 360 l/Min. | | X | 2 x1,1 kW | - | | V-MEKO 400/40W | 6 bar | 2 x 360 l/Min. | X | | 1,1 kW | - | | V-MEKO 250/W-MDR | 6 bar | 250 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 250/W-MIC | 6 bar | 250 l/Min. | X | | 1,1 kW | - | | V-MEKO 300/W-MDR | 6 bar | 300 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/W-MDR | 6 bar | 360 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/W-MDR-RW | 6 bar | 360 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/D-MDR | 6 bar | 360 l/Min. | | X | 1,1 kW | 24 kg | | V-MEKO 400/D-MDR-PMF | 6 bar | 360 l/Min. | | X | 1,1 kW | 24 kg | | V-MEKO 400/W-MDR-MIC-RW | 6 bar | 360 l/Min. | X | | 1,1 kW | 26 kg | | V-MEKO 400/W-RW | 6 bar | 360 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/W-RW-MIC | 6 bar | 360 l/Min. | X | | 1,1 kW | 24 kg | | V-MEKO 400/90W-DRAUSY | 6 bar | 360 l/Min. | X | | 1,1 kW | - | | V-MEKO 500/90W-Standard | 6 bar | 2 x 250 l/Min. | X | | 2 x 1,1 kW | - | | V-MEKO 800/300D | 6 bar | 2 x 360 l/Min. | | X | 2 x 1,1 kW | - | | Special voltages possible ! | | Trolly for all V-MEKOs | V-MEKO with two 40 l Tanks,
tested by German Lloyd for
use on ships. | SPRAYINGA uniform pressure profile is essential to obtain uniform spraying results. MEKOs guarantee air of unchanging constancy. COATING For the uniform application of all coarsegrained plasters and similar materials we recommend the ABN funnel spray gun for unique results. LACQUERINGOur MEKO series is characterized by the most constant air rates and unchanging pressure. Pressure drops are a thing of the past. FLOCKINGThe performance characteristics of the V-MEKO are perfectly tuned for applying textile plasters with a funnel spray gun. PLASTERING With their unique operational safety, reliability and high effective air rates, ABN MEKOs are ideal for the operation of plastering machines. They can be used as integrated or mobile machines. BREATCHING AIR SUPPLYIn our range of special models we offer customized ABN MEKOs designed to supply breathing air in compliance with DIN 3188. PNEUMATIC CONTROL Sensitive control systems need air rates of reliable constancy. MEKOs meet these requirements without difficulty. WATER TREATMENT Oxygen is important for the treatment of fresh water. We supply the necessary technology in our diaphragm compressors. Reliable, flexible and designed for continuous duty. Legend | MDR | - automatic switch-off device | | RW | - condenser prodection | | MIC | - fine dust filter and sound-damping | | A | - basic trolley | | MT | - reinforced trolley | | F | - filter pressure reducer | | PMF | - phase reversing switch | | |
